Invenio metal detector a new device from Nokta Detectors with un-preceded patented technology that scan ground layers and display real shape and size and depth of detected targets on its screen.
Invenio is the newest and all-new metal and gold detector
that will revolutionize the world of precious metal detection
and relics thanks to its new patented search technology.
The principle of this technology depends on a special search disk
that scans the area to be searched with a special tracking sensor
mounted on the disk arm in order to give the real shape of the
buried target for such as iron nail, box or coin …
In recent years, significant progress has been made in the field
of metal detector technology in terms of design and features.
but these features have not been able to meet the expectations
of treasure hunters and gold prospectors.
For example, gold prospectors want the device to include features
such as: Know the type of metal target discovered before digging
also need to know the depth of real targets, and know the shape
of buried targets and dimensions accurately … etc.
Invenio metal detector developed in response to these expectations after many years of tests and research.
so it provides a reliable and efficient system with the first intelligent system in the world to detect buried metals
then displaying a real shape of targets on screen as 3D graphics.
The search coil, which is equipped with special electrical coils, transfers the power generated
by the battery in the main control unit, resulting in a large-scale electromagnetic field
to achieve greater search depth than traditional devices.
When an electromagnetic field collides with a buried metal object such as an old coin,
a metal statue or a large box, the field signal is echoed in the form of another inverted electromagnetic field,
which is received by a receiver coil within the search coil.
The data is digitally converted and the signal is processed within the main unit of the search coil unit
and after the digital processing The data is transmitted wirelessly to the display unit, which has a coloured display
where the data is processed and displayed as a three-dimensional diagram that displays the detailed information
about the targets in the scanned area , so that the location information and the exact shape drawing depend
on the tracking data The tracking unit integrated position IPTU and that transmits data wirelessly also to the screen unit.
IPTU Sensor Function
IPTU (Integrated Positional Tracking Unit) includes integrated sensors to track the movement of the search coil
where the sensors record the coordinates of the coil and its height from the ground, which means recording
and tracking all movements of the coil (left – right or front to back ..) accurately represent these movements
directly on the unit that includes the screen visually , giving an accurate idea about coil movement within the search area.
This unit allows the prospector to determine the exact area of the search to be scanned by the search coil and the information recorded by it
, contributes in knowing the positions of the buried metallic objects as well as determining the length and width of the scan area
as well as the precise shape and distance of targets and the depth accurately.
With its unique imaging technology and the ability to detect all types of metals and even
underground spaces and cavity, so the Invenio metal detector is a versatile device that can
be used for a wide range of metal detection applications in the real life.
Here is a simple overview of some of the most important applications and uses of the device:
– Detecting gold and objects made of gold such as coins, old relics and ornaments such as rings and bracelets
– Prospecting for raw natural gold, which is found in shallow depths in the form of nuggets and small grains or veins in the ground.
– Detection of cavities and underground spaces such as tunnels, tombs, basements and so on.
– It can be used in municipal works such as detection of sewage pipes, telephone lines and water extensions (pipes)
– It can also be used to detect crimes and during police investigations by detecting weapons such as guns and pistols
The Invenio metal detector features a set of six metal search modes suitable for various applications and tasks.
However thhe search modes are divided into dynamic search modes (which require to move the search coil)
.as well as static search modes (no search coil movement required).
The following is a review of all search modes according to the previous two categories:
1 – Dynamic Search Modes
For this search mode, the search coil must be moved with a scrolling motion above the search area
in order to capture the buried metal targets.
In the case of walking the coil without moving it,
no sound or response will occur even if the coil is directly above the target.
Uses: It is preferable to use dynamic search modes to search for relatively small metal targets
such as small coins of gold or silver, rings and small ornaments, at small depths.
Invenio has three dynamic search modes:
1 – All Metal
2 – Fast
3 – Deep
2 – Static Search Modes
Here, in this search mode, there is no need to move the search disk to capture buried metal targets.
The user can walk the coil without moving it, but the disc discovers any metal object underneath.
The closer the coil is to the target, the higher the sound response.
Uses: These search modes are recommended for detection of relatively large metal targets,
such as huge metal statues, spaces and underground tunnels, and also it gives greater depth
in comparison with dynamic search modes.
Invenio has three dynamic search modes:
1- Basic mode
2 – Expert
3 – Ground Anomaly & Cavity
Metal Discrimination Features
When using one of the previous search modes and after performing the scan procedure,
the device displays the results on the screen unit and shows on the 3D graphics representation
the type of metal based on its color.
and thus, the user can know the metal type according to the color, so if the color is yellow
or gradients of yellow for example it may be a precious metal, such as gold or non-precious metal if its color of red gradients.
Wireless connection between different units
Communications and data transfers between the system box of the Invenio device (the main unit with the display screen)
and the coil unit (coil and shafts and IPTU) done wirelessly via Wi-Fi technology.
In addition, users who do not prefer wired headsets can purchase optional 2.4 GHz wireless headphones
to hear metal targets signals when detected.
Invenio features a vibration feature. when activated, the device will vibrate when a metallic target detected.
It is an essential feature for hearing for impaired users when searching in high noise areas where there are many noise sounds.
Save Scan Data
The user can save all three-dimensional graphics and screen shots from the ground scanning
then transfer it to his computer for better preview and more detailed analysis.
Device Software Update Feature
The device software updates available to download from the manufacturer’s website
so the device software updated by connecting the USB cable attached to the device and downloading updates to the device.
Front LED and back light of the screen
The Invenio Metal Detector has a front LED lamp to search in the dark,
and the screen has a back light to see the results of the scan even in the dark.
